McDantim Triple Blender Trumix with Inline Leak Detector

🚚 FREE SHIPPING on this item!
McDantimSKU: 811-TM-3+ILLI-(25/25/25)
Blend 1 (Co2/N2): 25/75
Blend 2 (Co2/N2): 25/75
Blend 3 (Co2/N2): 25/75
Price:
$1,746.36
✓ Drop Ships from Manufacturer - Lead times vary
EMPTY DOM REMOVE PROTECTOR
EMPTY DOM REMOVE PROTECTOR
EMPTY DOM REMOVE PROTECTOR
EMPTY DOM REMOVE PROTECTOR
EMPTY DOM REMOVE PROTECTOR

Description

When your long draw system needs to serve three distinct gas blends simultaneously, the McDantim Trumix® Triple Blender is the solution — mixing CO2 and N2 on demand across three independent channels with ±2% accuracy, so you can run nitrogenated stouts, high-CO2 German lagers, and domestic drafts all on one system without a single premixed cylinder.

Why Bar and Brewery Pros Choose the McDantim Trumix® Triple Blender

Why bar and brewery pros choose this

  • Three custom blends, built to order — Each unit is configured to your specified CO2/N2 ratios across all three channels, giving you maximum flexibility for diverse tap lineups.
  • Upgraded metal body inlet regulators — Increased durability and safety with a maximum safe working pressure up to 325 psi.
  • No electrical setup required — Wall-mounts easily and installs without wiring; shuts off automatically if either supply gas fails or runs empty.
  • High-capacity flow — Up to 26 kegs/hour per blend at 110 psi inlet pressure; flow range of 0.4–40 L/min (0.85–85 CFH).
  • 5-Year Limited Warranty — McDantim backs every Trumix® blender with a full 5-year limited warranty.
  • INCLUDES Plug & Play In-Line Leak Indicator — For enhanced system monitoring.

Specs & compatibility

  • Size: 9.5" W (including mounting flanges) × 10" H × 4.5" D
  • Connections: Two inlet gas lines (CO2 & N2); one mixed gas outlet line per blend
  • Fittings: Standard 1/4" female NPT; hose barbs available at no charge in 1/4", 5/16", and 3/8"
  • Inlet pressure range: 55–150 psi standard (customizable); upgraded regulators rated to 325 psi max
  • Outlet pressure: Adjustable 0–60 psi per blend (always 10 psi below minimum inlet pressure)
  • Accuracy: ±2% of full scale within 0.4–40 L/min flow range

Not sure which blends you need? Download the McDantim EasyBlend app (Android & iOS) to calculate your ideal CO2/N2 ratios before ordering.

Installation Instructions (PDF)

Frequently Asked Questions

  • What is a Triple Blender used for? It is used to create three independent CO2/N2 gas blends for long draw draft systems, allowing different beverages to be served from one setup.
  • Can it be used for draft beer service? Yes, it is designed for bar and brewery draft applications, including nitrogenated stouts, lagers, and domestic drafts.
  • Does it require power? No, the unit does not require electrical setup or wiring.

Product documents
SS - Slider #16 AI Image 1

Never Guess a Keg Level Again

The Kegtron Pro Dual Tap monitors two kegs in real time — pour by pour, from any device, anywhere in your bar or brewery.

Shop Kegtron Pro

SS - Slider #16 AI Image 2

Built for Dual-Tap Setups

Two flow sensors, one compact controller. Track remaining volume on both lines simultaneously with precision flow metering.

Shop Kegtron Pro

SS - Slider #16 AI Image 3

Wireless Monitoring, Anywhere

Wi-Fi connected and app-enabled — check pour counts and keg levels from your phone without ever walking to the cooler.

Shop Kegtron Pro

SS - Slider #16 AI Image 4

Cut Waste, Reorder Smarter

Know exactly when a keg is running low so you can reorder ahead of time and never blow a tap during a rush.

Shop Kegtron Pro

SS - Slider #16 AI Image 5

Trusted by Bars & Breweries

From taprooms to multi-location bars, Kegtron Pro delivers reliable, real-time draft data at an affordable price.

Shop Kegtron Pro

Frequently Asked Questions

The Triple Blender has three independent blending channels, each set to a different CO2/N2 ratio. This lets you simultaneously serve three distinct beer styles — such as a nitro stout, a domestic draft, and a high-CO2 German lager — from a single unit without premixed cylinders.

The Trumix® Triple Blender mixes CO2 and nitrogen (N2) on demand across three independent channels. It's ideal for long draw draft beer systems running a variety of beer styles that require different gas blends.

Yes. Each unit is custom-built to your specified CO2/N2 ratios across all three channels at the time of order. Use the free McDantim EasyBlend app (Android & iOS) to calculate your ideal ratios before placing your order.

Each channel delivers ±2% accuracy of full scale within a flow range of 0.4–40 L/min (0.85–85 CFH), ensuring consistent, repeatable pours across every tap on your system.

No. The Trumix® Triple Blender is fully mechanical — no electrical setup is required. It wall-mounts easily and shuts off automatically if either supply gas fails or runs empty.

McDantim backs every Trumix® blender with a 5-Year Limited Warranty covering defects in materials and workmanship.
