Chill-Max 1/2 HP Double Pump Glycol Power Pack, 4080 BTU's

MUST SHIP FREIGHT — CANNOT SHIP UPS GROUND

Chill-Max 1/2 HP Double Pump Glycol Power Pack — 4080 BTU

Commercial glycol chiller with dual pump circulation for long draw draft beer systems up to 225 ft. The 4080 BTU cooling capacity and twin pumps provide redundant glycol flow — one pump failure won't take down the whole system. Includes a digital thermostat for precise glycol bath temperature control.

Specifications

• 1/2 HP air-cooled compressor
• R134A Refrigerant
• Digital Thermostat
• Bath Capacity: 17 GAL / 64L
• Chilling Capacity: 4080 BTU/HR
• 120V, 60HZ, 15 AMP Circuit
• Max. Distance to Tower: 225' / 68M

Service Manual (PDF)

Warranty

18 months parts & labor from date of installation (not to exceed 19 months from shipment). Compressor warrantied for an additional 42 months. Circulation pumps and motors are excluded from all warranties — 30 days only to cover startup. Installation cost to replace a compressor after 18 months is the responsibility of the end user.

Also available: 1/2 HP Single Pump version ($2,950) | 3/4 HP Double Pump 6138 BTU ($4,050)
